3. Washer
4. Nut
We recommend that you change the grooving and chamfering wheels every 5,000 grooves or chamfers.
Have the following to hand:
• Allen key
• Open-ended spanner
• Wheel(s) to be replaced:
◦ Grooving wheel
◦ Chamfering wheel
From the work screen of the edger, select > > to change the grooving or chamfering wheel.
You can access the tool-change menu by pressing on the work screen.
Changing both wheels at the same time
The menu is designed to replace only one wheel at a time. If you are replacing both wheels at the
same time, simulate a replacement of the second wheel so that the wear statistics are also reset.
To do this, press the button corresponding with the second wheel, then to validate, without
touching the wheel shaft.
Replacing the grooving or chamfering wheel
Press the button corresponding with the wheel to be replaced:
• Grooving wheel
• Chamfering wheel
The GMD module moves to facilitate the operation.
