UMG70XV3-4EN 12.01.2009 153
18 Outputs
The source items and their scroll lists are described in Table 18.1.
Table 18.1: Configuration of the outputs
source item list item output
MEASURED VALUE ACTUAL MEASURE physical quantity selected in the program branch
OUTPUT OPTIONS
FLOW flow independently of the physical quantity select-
ed in the program branch OUTPUT OPTIONS
HEAT FLOW heat flow independently of the physical quantity
selected in the program branch OUTPUT
OPTIONS
QUANTITY Q+ totalizer for the positive flow direction
* ACTUAL MEASURE totalizer for the physical quantity selected in the
program branch OUTPUT OPTIONS
* FLOW flow totalizer
* HEAT FLOW heat flow totalizer
Q- totalizer for the negative flow direction
* ACTUAL MEASURE totalizer for the physical quantity selected in the
program branch OUTPUT OPTIONS
* FLOW flow totalizer
* HEAT FLOW heat flow totalizer
Q sum of the totalizers (positive and negative flow
direction)
* ACTUAL MEASURE totalizer for the physical quantity selected in the
program branch OUTPUT OPTIONS
* FLOW flow totalizer
* HEAT FLOW heat flow totalizer
LIMIT R1 limit message (alarm output R1)
R2 limit message (alarm output R2)
R3 limit message (alarm output R3)
TEMPERATURE Is available only if a temperature input has been
linked to the channel.
T-INLET (T1) supply temperature for the heat flow
measurement
T-OUTLET (T2) return temperature for the heat flow measurement
T(3)=INPUT T3 further temperature input
T(4)=INPUT T4 further temperature input
TV(=T1)-TR(=T2) difference between supply and return
temperature
TV(=T1)-T3 difference between supply temperature and T(3)
TR(=T2)-T3 difference between return temperature and T(3)
TV(=T1)-T4 difference between supply temperature and T(4)
TR(=T2)-T4 difference between return temperature and T(4)
T3-T4 difference between T(3) and T(4)
IMPULS FROM ABS(X) pulse without sign consideration
FROM X > 0 pulse for positive measured values
FROM X < 0 pulse for negative measured values
MISCELLANEOUS SOUNDSPEED FLUID sound velocity of the medium
CONCENTRATION K concentration
SIGNAL signal amplitude of a measuring channel
