PLC Output to FT-111 Input
1st
Dword
(OUTPUT)
Next Dword defines the usage of this Dword.
2nd
Dword
(OUTPUT)
Out
5
Out
4
Out
3
Out
2
Out
1
Expanded Commands List
Not in use
Command List
Read Data Selection
New
CMD
Description of Input 2
nd
Dword (OUTPUT)
Bit Number
Descriptions
Set / Reset digital outputs
Expanded Commands List (Refer to Table 12-4)
Not in use
Command
List
Bin
Dec
Commands
00000
0
None command is activated
00001
1
Zero
00010
2
Tare
00011
3
Clear
00100
4
Print
00101
5
Adjust zero calibration
Calibration
00110
6
Adjust span calibration
(1)
00111
7
Total Load Cell Capacity
(1)
eCal
Coefficients
Refer to par.
[613]
01000
8
Average mV/V value
(1)
01001
9
Dead Load value
(1)
01010
10
Save the coefficients of eCal
01011
11
CN (Label number)
(1)
01100
01110
12
14
Not used
01111
15
Set Point-1
10000
16
Set Point-2
10001
17
Set Point-3
10010
18
Set Point-4
10011
19
Set Point-5
10100
11110
20
30
Not used
11111
31
Use the Expanded Command list (Refer to Table 12-4)
B5 ... B1
Read Data
Selection
00000
0
Actual weight ( Net if the indication is in Net )
00001
1
Gross weight
00010
2
Tare weight
00011
3
ALL Status ( Refer to Table 12-2 )
00100
4
Calibration Status ( Refer to Table 12-3 )
00101
5
Last print value
00110
01010
6
10
Not used
01011
11
CN (Label number)
01100
01110
12
14
Not used
01111
15
Set Point-1
10000
16
Set Point-2
10001
17
Set Point-3
