FT-111, User Manual Rev. 2.0.0, June 2022 Page 129 of 137
Calibration Status (always 32 bit integer)
1(R_UL1) of PLC Output to FT-111 Input.
Bit Number
Low Dword of TxPDO 1(T_UL1) Description
Not in use
B10
0
No Error
1
- Check the calibration DIP switch.
B9
0
No Error
1
Scale unstable
- Wait until scale become stable
- Check grounding wiring
B8
0
No Error
1
Calibration load value entry Error
- Test weight is too small. Increase the weight
B7
0
No Error
1
Calibration Error
- Calibration loading is not enough
- Check test weight loading
- Check load cell connections
B6
0
No Error
1
Instrument cannot be calibrating
- Load cell signal is very low or too high
B5
0
No Error
1
Instrument cannot be calibrating
- Check load cell cable
- Re-energize the instrument
B4
0
No Error
1
ADC Error
- Re-energize the instrument
- If seen again, change the board.
B3
0
No Error
1
Calibration Timeout
- Restart calibration
B2
0
None
1
B1
0
None
1
B0
0
Not ready for calibration
1
Ready for calibration
Table 13.2 - Calibration status
