PLC Output to FT-111 Input
Bitwise of a Dword:
Unsigned
Long
(R/W)
B63
B62
B61
B60
B59
B58
B57
B56
B55
B54
B53
B52
B51
B50
B49
B48
B47
B46
B45
B44
B43
B42
B41
B40
B39
B38
B37
B36
B35
B34
B33
B32
B31
B30
B29
B28
B27
B26
B25
B24
B23
B22
B21
B20
B19
B18
B17
B16
B15
B14
B13
B12
B11
B10
B9
B8
B7
B6
B5
B4
B3
B2
B1
B0
RxPDO 1
(R_UL1)
Out
5
Out
4
Out
3
Out
2
Out
1
Expanded Commands List
Not in use
Command List
Read Data Selection
New
CMD
B33-B37 bits defines the usage of this Dword.
PLC Output to FT-111 Input RxPDO 1 (R_UL1)
Bit Number
RxPDO 1 (R_UL1) descriptions
B B56
Set / Reset digital outputs
B B48
Expanded Commands List (Refer to Table 13.3)
B B43
Not in use
B B38
Command
List
Bin
Dec
Commands
00000
0
No command is activated
00001
1
Zero
00010
2
Tare
00011
3
Clear
00100
4
Print
00101
5
Adjust zero calibration
Calibration
00110
6
Adjust span calibration
(1)
00111
7
Total Load Cell Capacity
(1)
eCal
Coefficients
Refer to par.
[613]
01000
8
Average mV/V value
(1)
01001
9
Dead Load value
(1)
01010
10
Save the coefficients of eCal
01011
11
CN (Label number)
(1)
01100
01110
12
14
Not used
01111
15
Set Point-1
10000
16
Set Point-2
10001
17
Set Point-3
10010
18
Set Point-4
10011
19
Set Point-5
10100
11110
20
30
Not used
11111
31
Use the Expanded Command list
(Refer to Table 13.3 )
B37 ... B33
00000
0
Actual weight (Net if the indication is in Net)
