FT-111, User Manual Rev. 2.0.0, June 2022 Page 131 of 137
Read Data
Selection
00001
1
Gross weight
00010
2
Tare weight
00011
3
ALL Status (Refer to Table 13.1)
00100
4
Calibration Status (Refer to Table 13.2)
00101
5
Last print value
00110
01010
6
10
Not used
01011
11
CN (Label number)
01100
01110
12
14
Not used
01111
15
Set Point-1
10000
16
Set Point-2
10001
17
Set Point-3
10010
18
Set Point-4
10011
19
Set Point-5
10100
11110
20
30
Not used
11111
31
Use the Expanded Command list
(Refer to Table 13.3)
B32
New CMD
Toggle
Apply commands which are listed in this table.
B31-B0
D33-D37 bits defines the usage of this Dword.
(1) Write this command after writing values to Low Dword of RxPDO then apply this command with New
CMD.
