FT-111, User Manual Rev. 2.0.0, June 2022 Page 53 of 137
[
178
FORM FE
:
NO
]
Form feed.
NO
YES
:
:
Disable
Enable
[
179
LEFT SP
:
3
]
Space from left of the label.
[
17A
COPY
:
1
]
Copy quantity.
[
19-
ANALOGUE OUT
]
ANALOGUE OUTPUT (Appears if the option is installed )
Press key or key again to enter this menu.
Press key to go to the beginning of the sub-block or press
key to go to the next main block.
[
191
TYPE
:
4-20
]
Analogue output type
4-20
0-20
0-10
0-5
:
:
:
:
4 mA - 20 mA
0 mA - 20 mA
0 VDC- 10 VDC
0 VDC- 5 VDC
[
192
MINIMUM
:
00.0
]
The minimum of the analogue output. Default 00.0 means the
minimum output is not drifted.
e.g. enter 1.0 to set output to 1.0 volt at 0 kg in 0 -10 V range.
[
193
MAXIMUM
:
00.0
]
The maximum of the analogue output. 00.0 means the maximum
output is not drifted.
e.g. enter 9.0 to set output to 9.0 volt at Max load in 0 -10 V range.
[
194
SOURCE
:
GROS
]
Source of the analogue output
GROS
INDI
:
:
Gross weight
Indicated weight
[
195
ZERO ADJ
:
]
Displays the count value of unloaded scale.
Increase or decrease by pressing or ; or enter the value by
pressing numerical keys to change the analogue output at zero
indication. and keys can be used for faster change.
[
196
SPAN ADJ
:
]
Displays the count value of the full loaded scale.
Increase or decrease by pressing or ; or enter the value by
pressing numerical keys to change gain of the analogue output.
and keys can be used for faster change.
[
197
AUTO ADJ
:
NO
]
Set analogue output to a new type or set to the original range.
NO
YES
:
:
No
Automatic adjustment the original range if changed.
Note: Set Minimum and maximum limits after automatic adjustment.
[
19-
PROFIBUS
]
PROFIBUS CONFIGURATION (Appears if the option is installed)
Press key or key again to enter this menu.
Press key to go to the beginning of the sub-block or press
key to go to the next main-block.
[
191
FORMAT
:
INTG
]
Data format of the Profibus
Page 101
