FT-111, User Manual Rev. 2.0.0, June 2022 Page 86 of 137
Comments :
SP Number is 2-byte ASCII char. Use 01 for SP1, 02 for SP2 and 03 for SP3.
SP VALUE data is 8-byte ASCII char with dot and non-significant zeros on the left.
R
Read set points
Command : [ADR][R][SP No][L]
Response : [ADR][R][STATUS][SIGN][SP VALUE]
Example :
Command : 01R01L
Response : 01RA+000123.4 (SP1 is 123.4)
01RN (Could not loaded)
Comments:
SP No is 2-byte ASCII char. Use 01 for SP1, 02 for SP2 and 03 for SP3.
SP VALUE data is 8-byte ASCII char with dot and non-significant zeros on the left.
S
Read Status
Command : [ADR][S]
Response : [ADR][S][STATUS-1][STATUS-2][STATUS-3]
Example :
Command : 01S
Response : 01SSGI (Stable, Gross, In Range)
01SDGL (Dynamic, Gross, Low voltage error)
Comments:
The response includes 3 status information.
STATUS-1 can be Stable or Dynamic.
STATUS-2 can be Gross or Net.
STATUS- -
T
Tare
Command : [ADR][T]
Response : [ADR][T][A] (Taring is done successfully and scale is in net)
[ADR][T][N] (Taring could not executed)
[ADR][T][X] (Taring is disabled)
Comments:
The tare value is overwritten by the new tare weight value.
Status must be stable in 2 seconds time out delay. If so, Ack is send.
If it cannot be stable in time out delay, Nack is send.
U
Read digital inputs
Command : [ADR][U]
Response : [ADR][U][STATUS][Inputs]
Example :
Command : 01U
Response : 01UA03 (Input 2 and Input 1 are active)
01UA96 (Input 8,5,3,2 are active)
01UAFF (All 8 inputs are active)
01UN (Could not read inputs)
Comments:
Data lengths change according to number of digital inputs.
Inputs are implemented to ASCII char of 4-
INPUTS
IN-8
IN-7
IN-6
IN-5
IN-4
IN-3
IN-2
IN-1
Bit wise
1
0
0
1
0
1
1
0
ASCII
9
6
