FT-111, User Manual Rev. 2.0.0, June 2022 Page 87 of 137
V
Read digital outputs
Command : [ADR][V]
Response : [ADR][V][STATUS][Outputs]
Example :
Command : 01V
Response : 01VA03 (Output 2 and Output 1 are active)
01VA96 (Output 8,5,3,2 are active)
01VAFF (All 8 outputs are active)
01VN (Could not read outputs)
Comments:
Data lengths change according to number of digital outputs.
Outputs are implemented to ASCII char of 4-
W
Write ( Set/Reset ) digital outputs
Command : [ADR][W][Outputs]
Response : [ADR][W][STATUS]
Example :
Command : 01W96
Response : 01WA (Outputs 8,5,3,2 are activated)
01WN (Outputs could not be activated)
Comments:
Data lengths change according to number of digital outputs.
Outputs are implemented to ASCII char of 4-
60).
Command : [ADR][X]
Response : [ADR][X][STATUS][SIGN][WEIGHT VALUE]
Example :
Command : 01X
Response : 01XS+00123.41 (weight is stable and 123.41) or
01XD+00123.41 (weight is dynamic and 123.41) or
01XE (Error)
Comments:The response includes weight data with divided the increment to 10.
Z
Zero
Command : [ADR][Z]
Response : [ADR][Z][A] (Zeroed)
[ADR][Z][N] (Zeroing could not be operated)
[ADR][Z][X] (Zeroing is disabled)
Comments :
Zero command cannot work in net weighing.
Weight must be in zeroing range for all operating modes.
Status must be stable in 2 seconds time out delay. If so, Ack is send.
If it cannot be stable in time out delay, Nack is send.
OUTPUTS
OUT-8
OUT-7
OUT-6
OUT-5
OUT-4
OUT-3
OUT-2
OUT-1
Bit wise
1
0
0
1
0
1
1
0
ASCII
9
6
OUTPUTS
OUT-8
OUT-7
OUT-6
OUT-5
OUT-4
OUT-3
OUT-2
OUT-1
Bit wise
1
0
0
1
0
1
1
0
ASCII
9
6
X
Read weight value in increased resolution
