2
XXXXXX
3
XXXXX.X
4
XXXX.XX
5
XXX.XXX
40161
R/W
2
Increment -1
Dec
Description
0
X 1
1
X 2
2
X 5
40163
R/W
2
MAX -2
40165
R/W
2
Decimal point-2
40167
R/W
2
Increment -2
40169
R/W
2
MAX -3
40171
R/W
2
Decimal point-3
40173
R/W
2
Increment -3
40175
R/W
2
Limit of Indication
Dec
Description
0
Over indication after Max.
1
1 division more than Max.
2
9 divisions more than Max.
3
2% more than Max.
4
5% more than Max.
40177
R/W
8
Not used
40185
R/W
2
Calibration
Command
s
Dec
Definition
0
None
188
Adjust Zero Calibration command
220
Adjust Span Calibration command
(first, load test weight value to 40187)
23205
Apply the coefficients of eCal
(first, load 40189, 40191 and 40193)
40187
R/W
2
Span Calibration Value
40189
R/W
2
Total Load Cell capacity for eCal
eCal
Coefficients
40191
R/W
2
Average mV/V value for eCal
40193
R/W
2
Dead load value for eCal
40195
R
2
Calibration
Process
Status
& Errors
Bit
Definition
B0
Ready for calibration
B1
B2
B3
Calibration Timeout
- Restart calibration
B4
ADC Error
- Re-energize the instrument
- If seen again, change the board.
B5
Instrument cannot be calibrating
- Check load cell cable
- Re-energize the instrument
B6
Instrument cannot be calibrating
- Load cell signal is very low or too high
B7
Calibration Error
- Calibration loading is not enough
- Check test weight loading
- Check load cell connections
