FOR-A HVS-3800HS User Manual

160
When FUNC was selected for the TYPE item
Setting Indication
- EDITOR ENABLE
ON: lit orange
OFF: unlit
- GPI IN ENABLE
M/E1
M/E2
SAFETY AREA PGM, SAFETY AREA PREV, SAFETY AREA
CLN
- SAFETY AREA AUX1-16
ON: lit orange
OFF: unlit
- SIDECUT AUX1-16
M/E1
M/E2
SIDECUT PGM, SIDECUT CLN, SIDECUT PREV
BUS INHIBIT
- GPI USER FLG 1- 16 (*1) Lit orange while pressing the button
M/E1
M/E2
LINE_DVE_PGM, LINE_DVE_PST,
LINE_DVE_KEY1-3
ON (On Air side): lit red or green
ON (Next side): lit orange, OFF: unlit
- KF DIRECTION NORMAL: unlit, REVERSE: lit orange
- STILL1-6 STORE Always lit orange
- WIPE BORDER ENABLE
ON: lit orange
OFF: unlit
- WIPE BORDER SIGNAL
- WIPE EDGE TYPE SQU / SAW/RIP
M/E1
M/E2
KEY1 INVERT
KEY1 MASK BOX_A / BOX_O / KEY3_A / KEY3_O
KEY1 MASK INVERT
KEY1 EDGE NORMAL
KEY1 EDGE OLINE
KEY1 SHADOW ENABLE
KEY2 INVERT
KEY2 MASK BOX_A / BOX_O / KEY3_A / KEY3_O
KEY2 MASK INVERT
KEY2 EDGE NORMAL
KEY2 EDGE OLINE
KEY2 SHADOW ENABLE
KEY3 INVERT
KEY3 MASK BOX_A / BOX_O
KEY3 MASK INVERT
-
WIPE MODIFY RESET
Always lit orange
DVE MODIFY RESET
ME1 BG-CC1 SEL(INPUT/BTN)
Lit orange when selected
Unlit at other times
(See section 14-8-1)
ME1 BG-CC2 SEL(INPUT/BTN)
ME1KEY-CC1 SEL(INPUT/BTN)
ME1KEY-CC2 SEL(INPUT/BTN)
ME2 BG-CC1 SEL(INPUT/BTN)
ME2 BG-CC2 SEL(INPUT/BTN)
ME2KEY-CC1 SEL(INPUT/BTN)
ME2KEY-CC2 SEL(INPUT/BTN)
AUX-CC1 SEL(INPUT/BTN)
AUX-CC2 SEL(INPUT/BTN)
COLOR CORRECT LED
Lit orange when selected
Unlit at other times
(See section 14-8-1)
COLOR CORRECT ME1 BKGD CH1
COLOR CORRECT ME1 BKGD CH2
COLOR CORRECT ME1 KEY CH1
COLOR CORRECT ME1 KEY CH2
COLOR CORRECT ME2 BKGD CH1
COLOR CORRECT ME2 BKGD CH2
COLOR CORRECT ME2 KEY CH1
COLOR CORRECT ME2 KEY CH2
COLOR CORRECT AUX CH1
COLOR CORRECT AUX CH2
(Continued to next page.)
