FOR-A HVS-3800HS User Manual

Upon Receipt
Unpacking
The Hanabi series switcher, HVS-3800HS and HVS-3800S, and any of their options you may
have purchased are fully inspected and adjusted prior to shipment and can be operated
immediately upon completing all required connections and operational settings. Check your
received items against the packing lists below.
 MU Box Contents
ITEM QTY REMARKS
HVS-3800HS/S 1 MU (Main Unit)
AC Cord 1
Rack Mount Brackets 1 pr.
 OU Box Contents
ITEM QTY REMARKS
HVS-16OUA
HVS-24OUA
HVS-12ROUA
1 OU (Operation Unit)
AC Cord 1
Control Cable 1 PC-3164 for Display Unit connection
Memory Card 1 Compact Flash memory card 512MB
Operation Manual 1 This manual
 Internal Hardware Options
ITEM QTY REMARKS 720/50p
HVS-38HSDI / SSDI
1
Digital component 12-input expansion
card
Available
HVS-38DVE2D / SDVE2D (*1)
1-2 HD/SD switchable 2D DVE card Available
HVS-38DVE3D SDVE3D (*1)
1-2 HD/SD switchable 3D DVE card Available
HVS-38AUMV
1 Auxiliary multi-viewer card
Unavailable
(*3)
HVS-38UC
1-4 Up-converter input card Unavailable
HVS-38DC
1 Down-converter output card Unavailable
HVS-38SS(*2) 1 Still store card Unavailable
HVS-38SSAM(*2) 1 Still store animation card Unavailable
HVS-38PSM
1
Modular redundant power supply unit
for MU
-
HVS-38PSO
1
Modular redundant power supply unit
for HVS-16/24OUA
-
HVS-12PSO 1
Modular redundant power supply unit
for HVS-12ROUA
-
(*1) Either HVS-38DVE2D or HVS-38DVE3D is installed to the MU. (Both not available.)
(*2) Either HVS-38SS or HVS-38SSAM is installed to the MU. (Both not available.)
(*3) The Multiviewer function does not support 720/50p, but the optional outputs added with this option
support 720/50p.
Each optional device (except factory installed ones) provides with the specific operation or installation
manuals.
 Software Options
ITEM QTY REMARKS
HVS-38CC / SCC 1 Color Corrector
HVS-38ED 1 Editor Control
