FoxGate S6424-S2C2 series User Manual

ACL Configuring
121
18.3.1 Configuration Procedure
Follow these steps to configure a basic ACL
Table 18-2 Configure basic ACL based on digital identification
Command
Operation
remark
Enter global configuration mode
configure terminal
-
Define sub-item match rule
access-list num match-order { config |
auto }
optional
by
default ,syste
m is config
Define basic ACL
access-list num { permit | deny }
{ source-IPv4/v6 source-wildcard |
any | ipv6any } [ time-range name ]
required
Table 18-3 Configure basic ACL based on name identification
Command
Operation
remark
Enter global configuration
mode
configure terminal
-
Define sub-item match rule
access-list standard name match-order
{ config | auto }
optional
by default ,system is
config
Define basic ACL and enter
configuration mode
access-list standard name
required
Configure ACL rule
{ permit | deny } { source-IPv4/v6
source- wildcard | any | ipv6any }
[ time-range name ]
required
18.3.2 Configuration Examples
！Define a basic ACL with number mark to deny packet with source IP 10.0.0.1
Switch#configure terminal
Switch(config)#access-list 1 deny 10.0.0.1 0
!Define a basic ACL with name mark to deny packet with source IP 10.0.0.2
Switch#configure terminal
Switch(config)#access-list standard stdacl
Switch(config-std-nacl-stdacl)#deny 10.0.0.2 0
18.4 Define Extended ACL
Switch can define at most 100 extended ACL with the number ID (the number is in the
range of 100 to 199), at most 1000 extended ACL with the name ID. It can define 128
