FoxGate S6424-S2C2 series User Manual

Port Isolation Configuration
65
8.2.2 Port-isolation Monitor and Maintenance
After finishing above configuration, user can check the configurations by command below.
Table 8-2 Port-isolation monitor and maintenance
Operation
Command
Remarks
Show isolate-port configuration
show isolate-port
On any
configuration mode
8.3 Port-isolation Configuration Example
8.3.1 Port-isolation Configuration Example
I. Network requirements
User PC1，PC2，PC3 connect to switch e0/0/2，e0/0/3，e0/0/4. Switch connects to Internet
by e0/0/1. User PC1，PC2，PC3 need independent data exchange.
II. Networking diagram
III. Configuration procedure
Switch#configure terminal
Switch(config)#isolate-port ethernet 0/0/2 to ethernet 0/0/4
Add port isolation downlink port successfully.
Switch(config)#show isolate-port
Port isolation downlink port :
e0/0/2-e0/0/4
