FoxGate S6424-S2C2 series User Manual

EFM configuration
260
34.2.5 Configuring Link Monitoring Capabilities
Table 34-7 Configure link monitoring capabilities
Operation
Command
Remarks
Enter global configuration
mode
configure terminal
-
Enter port configuration
mode.
interface ethernet device / slot / port
-
Start link monitoring
capabilities
efm link-monitor {errored-symbol-period
| errored-frame | errored-frame-period |
errored-frame-seconds}
Optional
By default, the link
monitoring is
enabled
Configure
errored-symbol-period
event detection cycle
efm link-monitor errored-symbol-period
window high win-value1 low win-value2
Optional
Configure
errored-symbol-period
event detection threshold
efm link-monitor errored-symbol-period
threshold high th-value1 low th-value2
Optional
Configure errored-frame
event detection cycle
efm link-monitor errored-frame window
win-value
Optional
Configure errored-frame
event detection threshold
efm link-monitor errored-frame
threshold th-value
Optional
Configure
errored-frame-period event
detection cycle
efm link-monitor errored-frame-period
window win-value
Optional
Configure
errored-frame-period event
detection threshold
efm link-monitor errored-frame-period
threshold th-value
Optional
Configure
errored-frame-seconds
event detection cycle
efm link-monitor errored-frame-seconds
window win-value
Optional
Configure
errored-frame-seconds
event detection threshold
efm link-monitor errored-frame-seconds
threshold th-value
Optional
Description:
errored-symbol-period threshold event detection cycle and a 64-bit integer value, high and
low parameter values, respectively, after the value of the high and low 32-bit, that is, the
integer value = (high * (2 ^ 32)) + low.
34.2.6 Enabling Remote Loopback
By default, loopback at the far end is in the off state. It can only support the far end
loopback device starts far end loopback.
