CFM Configuration
Create a maintenance endpoint,
and specify its associated port
cfm mep mep-id direction {up | down}
[primary-vlan vlan-id] interface
ethernet port-id
Enable the state to maintain
endpoint management
cfm mep mep-id state {enable |
disable}
CCM and configure the endpoint
to send maintenance to use the
priority LTM
cfm mep mep-id priority priority-id
Optional
Default
priority is 0
31.2.7 Configure Remote Maintenance Endpoint
Remote maintenance end point is equivalent to the local maintenance of the end points,
and in the maintenance of concentration, in addition to the maintenance of the local endpoint,
all other maintenance endpoints should be configured in the local endpoint for the remote
maintenance.
Table 31-9 Configure Remote Maintenance endpoint
Enter global configuration mode
To maintain the domain configuration mode to
enter
Enter the configuration mode set to maintain
Creating remote maintenance end point, and
specify the end of its peer MEPs
cfm rmep rmep-id mep mep-id
31.2.8 Configuring MIPs
MIPs used to test the response of CFM message, the user can program the network
device or in non-border ports configured to maintain the mid-point.
Table 31-10 Configuring MIPs
Enter global configuration mode
To maintain the domain configuration
mode to enter
Enter the configuration mode set to
maintain
Create a maintenance intermediate
point, and specify its associated port
cfm mip mip-id interface ethernet
port-id
31.2.9 Configuration Continuity Detection
Continuity detection through configuration, can be made to maintain interoperability
between endpoint CCM packets to check the connectivity between these endpoints maintain
state in order to achieve the link connectivity management.
