FoxGate S6424-S2C2 series User Manual

Configuring MSTP
186
Table 23-4 Configure MSTP identifier
Operation
Command
Remark
Enter global configuration mode
configure terminal
-
Configure MSTP identifier name
spanning-tree mst name name
optional
Configure MSTP identifiers
revision
spanning-tree mst revision revision-level
optional
Configure MSTP instance
configuration and VLAN identifier
mapping
spanning-tree mst instance instance-num vlan
vlan-list
optional
23.4.5 Configuring MSTP Bridge Priority
In MSTP, the bridge priority is based on the parameters of MSTI, the bridge priority
together with port priority and port path cost determines the topology of each spanning tree
instance, constitute the basis for link load balancing.
Switch bridge priority determines the size of this switch is able to be selected as the
spanning tree root bridge. By configuring the bridge priority of the smaller, you can specify a
switch to become the spanning tree root bridge purposes.
By default, the switch bridge priority is 32768.
Table 23-5 Configure MSTP bridge priority
Operation
Command
Remark
Enter global configuration
mode
configure terminal
-
Configure MSTP instance
priority
spanning-tree mst instance instance-num priority
priority
optional
23.4.6 Configuring Port Boundary Port Status
Border and port means connected to the host ports that can linkup within a very short time
after entering the forwarding state, but once these ports receive spanning tree packets will
automatically switch to non-border ports.
Table 23-6 Configure the port boundary port status
Operation
Command
Remark
Enter global configuration mode
configure terminal
-
Enter port configuration mode
Interface ethernet
interface-num
-
Configure the port boundary port status
spanning-tree mst portfast
optional
