FoxGate S6424-S2C2 series User Manual

MLD Snooping
278
Chapter 40. MLD Snooping
40.1 MLD Snooping Overview
MLD (Multicast Listener Discovery) Internet Group Management Protocol is part of the
IPv6 protocol, to support and manage hosts and multicast routers IP multicast. IP Multicast
allows the transmission of IP packets to a multicast group constitutes a set of host, multicast
group membership relationship is dynamic, host can dynamically join or leave the group, so to
minimize the network load, effective online data transfer.
MLD Snooping is used to monitor hosts and routers between the MLD messages,
according to group members join, leave, and dynamically create, maintain and delete the
multicast address table, this time, multicast frames based on their respective multicast
address table be forwarded.
40.2 Configuring MLD Snooping
40.2.1 MLD Snooping Configuration Task List
Table 40-1 MLD Snooping Configuration Task List
Configuration Tasks
Remark
Detailed
configuration
Basic MLD Snooping
Configuration
Start MLD Snooping
Required
40.2.2
Adjust and optimize the
MLD Snooping
Configuration
Configure dynamic multicast
member port aging time
Optional
40.2.3
Configure the maximum response
time to leave
Optional
40.2.3
Fast-leave configuration port
Optional
40.2.4
Maximum number of learning
multicast configuration port
Optional
40.2.5
Configuring MLD-Snooping
Multicast Learning Strategies
Optional
40.2.6
Configuring MLD-Snooping
querier
Optional
40.2.7
Configuring Routing port
Optional
40.2.8
Multicast VLAN port configuration
Optional
40.2.9
Display and maintenance of MLD Snooping
Optional
40.2.10
