FoxGate S6424-S2C2 series User Manual

QoS Configuration
138
20.2.9 Configuring Mapping Relationship between
DSCP and 8 Priority in IEEE 802.1p
The same situation as 1.2.7, by default , the relation between DSCP and 8 priority in IEEE
802.1p as below;
Table 20-14 Relation between DSCP and 8 priority in IEEE 802.1p
SCP
hardware
priority
queue
DSCP
hardware
priority
queue
DSCP
hardware
priority
queue
DSCP
hardware
priority
queue
0
0
16
1
32
2
48
3
1
0
17
1
33
2
49
3
2
0
18
1
34
2
50
3
3
0
19
1
35
2
51
3
4
0
20
1
36
2
52
3
5
0
21
1
37
2
53
3
6
0
22
1
38
2
54
3
7
0
23
1
39
2
55
3
8
0
24
1
40
2
56
3
9
0
25
1
41
2
57
3
10
0
26
1
42
2
58
3
11
0
27
1
43
2
59
3
12
0
28
1
44
2
60
3
13
0
29
1
45
2
61
3
14
0
30
1
46
2
62
3
15
0
31
1
47
2
63
3
Administrators also change the mapping relationship between DSCP and 8 priority in IEEE
802.1p according to the actual network.
Table 20-15 Configuring the relation between DSCP and 8 priority in IEEE 802.1p
Operation
Command
remark
Enter globally configuration mode
configure terminal
-
Startup the relation between
DSCP and 8 priority in IEEE
802.1p
queue-scheduler dscp-map
required
by default, it is disable.
Modify the relation between
DSCP and 8 priority in IEEE
802.1p
queue-scheduler dscp-map
dscp-value 802.1p-priority
optional
20.2.10 Configuring Flow Statistic
Flow statistic configuration is used to statistic specified service flow packet. The statistic is
accumulated value and reset to zero when re-configuring.
