Page #277 background imageLoading...
Page #277 background image
Port-car Configuration
275
Chapter 38. Port-car Configuration
38.1 Port-car Overview
Port-car can protect switch from packet attacking whose destination MAC begins with
01:80:c2. Most of L2 protocol packets (such as BPDU packets of STP) whose destination
MAC begins with 01:80:c2 will send to CPU. After enabling Port-car, the packet rate will be
controlled under the configured threshold.
Table 37-5 summarizes common protocol packets whose destination MAC begins with
01:80:c2.
Table 37-5 Protocol packets begin with 01:80:c2
MAC
Protocol
01-80-c2-00-00-00
BPDU packet
01-80-c2-00-00-01
Suspended Flow-control packet
01-80-c2-00-00-02
802.3ad LACP packet
01-80-c2-00-00-03
802.1X packet
01-80-c2-00-00-0e
LLDP packet
01-80-c2-00-00-10
Flexlink MMU packet
01-80-c2-00-00-20
GMRP packet
01-80-c2-00-00-21
GVRP packet
38.2 Configure Port-Car
Perform following commands in global configuration mode.
Table 37-6 Configure port-car
Operation
Command
Description
Enter global configuration mode
configure terminal
Enable global port-car
port-car
By default, port-car is
enabled.
Configure global port-car rate
port-car-rate rate pps
By default, the rate is
780pps.
Enter interface configuration
mode
interface ethernet interface-num
-
Enable port-car(in interface
configuration mode)
port-car
By default, port-car is
enabled in each FE
port.
Configure interface port-car rate
port-car-rate rate
By default, the rate is
30pps.
