Paper Jams
669
Problem Solving
15
5
Remove the jammed paper.
z
The fusing unit is extremely hot. Do not touch the fusing unit as it may result in burn injury.
z
If the paper is torn, make sure no piece of paper remains inside the machine.
6
Return the lever A1 to the original position, and close the chute of the fusing unit.
7
Push the center of the top left cover and close the cover gently.
Paper Jams in Center Tray Exit
1
While lifting up the release lever (1), gently open the top left cover (2).
îš„When the Side Tray is installed
Remove paper from the Side Tray (1), close the Side Tray (2), and then open the top left
cover.
To Next Page
