Paper Jams
693
Problem Solving
15
2
Pull out the Tri-fold output tray [2d] (1), and move the handle [2e] to the right (2). Remove
the jammed paper (3).
z
If paper is torn, check for any torn pieces of paper inside the machine.
3
If you cannot remove the paper in step 2, return the handle [2e] to its original position (1),
and move the handle [2f] (2). Turn the knob [2c] to the left (3), and then remove the
jammed paper (4).
z
If paper is torn, check for any torn pieces of paper inside the machine.
4
Return the handle opened ([2f] or [2e]) to its original position (1), and push the Tri-fold
output tray [2d] in (2).
5
Close the folder unit cover of the Folder Unit CD1.
z
A message will be displayed and the machine will not operate if the folder unit cover of the Folder Unit CD1 is
even slightly open.
To Next Page
