Paper and Other Media
72
Paper and Other Media
2
7
Pull up the lever of the end guide (1). Move the lever along the slot, and set it at the position
corresponding to the paper size (2). And then press the lever down (3).
z
Adjust the end guide correctly to the size of the paper. If the end guide is not adjusted correctly, the machine
cannot feed the paper properly, resulting in paper jams.
z
The slot on the left of 8.5" is not used.
8
Open the end guide (1), and load and align the edge of the paper against the right edge of
the tray with the side to be copied or printed on facing down (2).
z
Do not load paper above the maximum fill line ("MAX" in the right figure). It may cause paper jams or
machine malfunction.
9
Close the end guide securely.
10
Push the tray in gently until it stops.
To Next Page
