Specifications
737
Appendix
16
that can be stapled, one Z-fold sheet of A3 or 11 x 17" paper is equivalent to 10 sheets of unfold paper and
one Z-fold sheet of other size of paper is equivalent to 20 sheets of unfold paper. If the curl in the paper is
very strong, the output paper may not be stapled properly.
z
Paper size
Maximum: A3, 11 x 17"
Minimum: B5
z
Position
1 position or 2 positions
z
When using 64 gsm paper
îš„ Punch
z
Number of holes : 2/4 holes, US 2/3 holes (US Specifications)
z
Paper size
A3, 11 x 17", B4, A4
*
, A4 , Letter
*
, Letter , B5 , 7.25 x 10.5" (184 x 267 mm), 8 x 10"
(203 x 254 mm)
*
, 16K (194 x 267mm) , Cover A4 (223 x 297 mm), 9 x 11" (229 x 279
mm) , 215 x 315 mm, 8.5 x 13" (216 x 330 mm)
*
, Legal (8.5 x 14"), 11 x 15" (279 x 381
mm), 8K (267 x 388 mm)
* : The 3 holes (optional) are not available.
z
For punching, Punch Unit 2/4H CD1 (optional) or Punch Unit US 2/3H CD1 (optional) is required.
z
You can switch the number of punch holes between 2 holes and 4 holes with the Punch Unit 2/4H CD1
(optional), and US 2 holes and US 3 holes with the Punch Unit US 2/3H CD1 (optional).
z
Paper weight : 52 - 200 gsm
z
When using P paper
îš„ Dimensions
Width 730 x Depth 589 x Height 1,056 mm
Width 965 x Depth 726 x Height 1,056 mm (with the Fold Unit CD1)
z
When the Transport Unit H3 (optional) is installed and the extension tray is fully extended.
îš„ Weight
44 kg
98 kg (with the Fold Unit CD1)
z
Icluding the Transport Unit H3
îš„ Space Requirement (with the main unit)
Width 1,772 x Depth 791 mm (Main unit + C3 Finisher)
Width 2,009 x Depth 791 mm (Main unit + C3 Finisher + Fold Unit CD1)
z
When the paper support is pulled out and the Bypass tray is fully extended.
To Next Page
