9 Paper and Other Media
274
Paper and Other Media
9
Loading Paper in Trays 6 to 7
Following describes the procedure for loading paper in the optional trays 6 to 7.
For information about changing the paper size and orientation, refer to"Changing the Size of Paper in
Trays 6 to 7" (P.279).
1 Pull out the tray towards you until it
stops.
Important • While the machine processes
a job, do not pull the tray out
that the job uses.
2 Load and align the edge of the
paper against the right edge of the
tray with the side to be copied or
printed on facing up.
Note • Do not load paper exceeding
the maximum fill line. Doing so
might cause paper jams or
machine trouble.
3 Push the tray in gently until it comes to a stop.
When pulling out the paper tray,
do it slowly. If pulled out with too
much force, the tray can hit and
injure your knees.
MAX
To Next Page
