HP-GL2 Emulation
595
Specifications
16
7. Restrictions When Plotting under Auto Layout
îš„If the Printer is Equipped with Hard Disk(s)
When Auto Layout is used, print data is stored on the hard disk.
îš„If the Printer is Not Equipped with hard disk(s)
When Auto Layout is used, print data is stored in layout memory.
The default layout memory is set at 100kbyte. Consequently, when print data
exceeding 100kbyte is received, a printer error occurs.
If this happens, change the Auto Layout memory capacity on the operation panel.
However, the Auto Layout memory capacity max is 5120kbyte. So, print data larger
than 5120kbyte cannot be received.
When using the Auto Layout function, we recommend the printer be equipped with a
hard disk.
8. Examples of Combinations of Each Function
The following are examples showing the print results that can be achieved by
combining various functions.
îš„Document: Auto, Coordinate Origin: 0 Degrees, Scaling Mode: Paper Size,
Scaling: ON
îš„Document: Auto, Coordinate Origin: 0 Degrees, Scaling Mode: Paper Size,
Scaling: OFF
Print Area
Document Size
Paper Size
Print Area
Document Size Paper Size
To Next Page
