BX924 S4 Upgrade and Maintenance Manual 283
Appendix
12.3.2 Connectors and indicators on the front panel
12.3.2.1 Front panel connectors
Figure 129: Front panel connectors
Pos. Component
1 Y-cable port
2 USB connector
