Fujitsu PRIMERGY RX2530 M6

Figure 91: Removing the rear HDD/SSD cage
▶
Remove the three screws (see circles).
▶
Remove the rear HDD/SSD cage upward.
Figure 92: Removing the rear HDD/SSD backplane
▶
Release the green screw (see circle).
▶
Remove the rear HDD/SSD backplane upward.
Hard disk drive (HDD) / solid state disk (SSD)
RX2530 M6 Upgrade and Maintenance Manual 171
