Tools: – Phillips PH2 / (+) No. 2 screw driver (for cover 2)
– Torx Plus 6 screw driver (not valid for Japan)
–
Phillips PH1 / (+) No. 1 screw driver (Japan)
Preliminary steps
▶
"Locating the defective server" on page 45.
▶
"Removing backup and optical disk media" on page
78.
▶
"Suspending BitLocker functionality" on page 75.
▶
If applicable, "Removing the front cover with lock" on page 48.
▶
"Shutting down the server" on page 48.
▶
"Disconnecting the power cord" on page 49.
▶
"Getting access to the component" on page 52.
Removing the defective ODD
▶
Remove the ODD, see "Removing the ODD" on page 320.
Installing the new ODD
▶
Install the ODD, see "Installing the ODD" on page 317.
Concluding steps
▶
"Reassembling" on page 57.
▶
"Connecting the power cord" on page 62.
▶
"Switching on the server" on page 66.
▶
If applicable, "Installing the front cover with lock" on page 66.
▶
"Resuming BitLocker functionality" on page 93.
Accessible drives
RX2530 M6 Upgrade and Maintenance Manual 323
