Preliminary steps
▶
If applicable, "Removing the front cover with lock" on page 48.
▶
"Shutting down the server" on page
48.
▶
"Disconnecting the power cord" on page 49.
▶
"Getting access to the component" on page 52.
▶
Remove the riser module 1, see "Removing a riser module" on page 69.
Installing the Dual microSD 64GB Enterprise
Figure 270: Installing the microSD card
▶
Install the microSD card on the top side (1) or on the bottom side (2) or in
both sides in the corresponding slot. For the installation of the microSD card,
see "Replacing the Dual microSD 64GB Enterprise" on page 379.
System board and components
RX2530 M6 Upgrade and Maintenance Manual 373
