Figure 103: Removing the slot cover
▶
Pull down the latch (1).
▶
Remove the slot cover (2).
CAUTION
▶
Keep the slot cover for future use.
▶
If the expansion card is removed and not replaced with a new
one, the slot cover must be reinstalled due to cooling, to comply
with applicable EMC regulations and to protect against fire.
Expansion cards and backup units
RX4770 M6 Upgrade and Maintenance Manual 197
