Connect all cables to the system board:
– COP cable (front panel cable)
– Power cable for HDD backplane
– SAT
A cable for ODD
–SATA power cable for ODD
– Front VGA cable
– OOB cable
For the cable plan, see "Appendix A" on page 387.
Concluding steps
▶
If applicable, install the Dual microSD 64GB Enterprise, see "Installing the
Dual microSD 64GB Enterprise" on page 361.
▶
If applicable, install all M.2 SSDs, see "Installing the M.2 SSD" on page 353.
▶
If applicable, install the iRMC microSD card, see "Installing the iRMC
microSD card" on page 345.
▶
If applicable, install the TPM, see "Installing the TPM" on page 332.
▶
If applicable, install the OCP module, see "Installing the OCP module" on
page 189.
▶
Install all memory modules on the bottom system board, see "Installing a
memory module" on page 245.
Ensure that you reinstall each memory module in the slot it was
located before the replacement.
CAUTION
In case of Optane PMem modules are not reinstalled in the right
slots, data can be lost!
▶
Install all memory dummy modules on the bottom system board, see
"Installing a dummy module" on page
253.
▶
Install the power distribution board, see "Replacing the power distribution
board" on page
129.
▶
If applicable, install the expansion cards from slot 3 to slot 9, see "Installing
an expansion card" on page 194.
System board and components
384 Upgrade and Maintenance Manual RX4770 M6
