SECTION 4: Repair
2025653-048 Revision B Responder
™
2000 Page 49
Assembly Step Details
Install Rear Body to Front
Body using five small Torx
security screws and two
large Torx security screws.
Note: Tighten all screws
slowly and evenly. Check
for bulges, gaps, or pinched
wires before tightening
completely.
Install Bed Hook Covers
using two Phillips screws.
Note: Ensure Bed Hook
Covers are properly
installed.
Figure 67: Rear Body Installed
Figure 68: Bed Hook Cover
Improperly Installed
(Right Cover on Left Side)
