Section 5: Performance Verification and Safety Testing
2025653-048 Revision B Responder
™
2000 Page 74
Leads Name Limit
3-7 Patient Auxiliary Current DC (OS) 50 µA
3-7 Patient Auxiliary Current DC (NC) 10 µA
3-7 Patient Auxiliary Current DC OE 50 µA
3-7 Patient Auxiliary Current DC OSRM 50 µA
3-7 Patient Auxiliary Current DC NCRM 10 µA
3-7 Patient Auxiliary Current DC OERM 50 µA
1-2 Patient Leakage Current DC (OS) 50 µA
1-2 Patient Leakage Current DC NC 10 µA
1-2 Patient Leakage Current DC OE 50 µA
1-2 Patient Leakage Current DC OSRM 50 µA
1-2 Patient Leakage Current DC NCRM 10 µA
1-2 Patient Leakage Current DC OERM 50 µA
3-7 Patient Leakage Current DC (OS) 50 µA
3-7 Patient Leakage Current DC (NC) 10 µA
3-7 Patient Leakage Current DC OE 50 µA
3-7 Patient Leakage Current DC OSRM 50 µA
3-7 Patient Leakage Current DC NCRM 10 µA
3-7 Patient Leakage Current DC OERM 50 µA
8 Patient Leakage Current DC (OS) 50 µA
8 Patient Leakage Current DC (NC) 10 µA
8 Patient Leakage Current DC OE 50 µA
8 Patient Leakage Current DC OSRM 50 µA
8 Patient Leakage Current DC NCRM 10 µA
8 Patient Leakage Current DC OERM 50 µA
2. Plug Cord from 120V, 60hz receptacle of Safety Analyzer into the wall outlet.
3. Plug cord from Auxiliary Power to Equipment Under Test receptacle of Safety Analyzer into Step-up
transformer output (264VAC).
4. Plug power cord from Responder 2000 into outlet on front of Safety Analyzer.
5. Plug jumper cable from ENCL connector to EARTH connector.
6. Plug the 5 ECG cable leads from ECG Cable Port into Patient Lead connectors 3-7.
7. Plug cable from Dfib Paddle Port into Patient Lead connectors 1 and 2.
8. (For SpO
2
equipped Responder 2000 only) Plug cable from Sp02 connector to Patient Lead connector 8.
