Grandstream Networks UCM6100 Series User Manual

P a g e | 113
UCM6100 Series User Manual
Version 1.0.18.13
Port
Configure the LDAP server port. The default value is 389.
Base DN
This is the location in the directory where the search is requested to begin.
Example:
• dc=grandstream, dc=com
• ou=Boston, dc=grandstream, dc=com
User Name
Configure the bind “Username” for querying LDAP servers. The field can
be left blank if the LDAP server allows anonymous binds.
Password
Configure the bind “Password” for querying LDAP servers. The field can be
left blank if the LDAP server allows anonymous binds.
Number Filter
Configure the filter used for number lookups. Please refer to user manual
for more details.
Name Filter
Configure the filter used for name lookups. Please refer to user manual for
more details.
Version
Select the protocol version for the phone to send the bind requests. The
default value is 3.
Name Attribute
Specify the “name” attributes of each record which are returned in the
LDAP search result.
Example:
• gn
• cn sn description
Number Attribute
Specify the “number” attributes of each record which are returned in the
LDAP search result.
Example:
• telephoneNumber
• telephoneNumber Mobile
Display Name
Configure the entry information to be shown on phone’s LCD. Up to 3 fields
can be displayed.
Example:
• %cn %sn %telephoneNumber
Max Hits
Specify the maximum number of results to be returned by the LDAP server.
Valid range is 1 to 3000. The default value is 50.
Search Timeout
Specify the interval (in seconds) for the server to process the request and
client waits for server to return. Valid range is 0 to 180. Default value is 30.
Sort Results
Specify whether the searching result is sorted or not. Default setting is No.
Incoming Calls
Configure to enable LDAP number searching when receiving calls. The
default setting is No.
Outgoing Calls
Configure to enable LDAP number searching when making calls. The
default setting is No.
