Grandstream Networks UCM6100 Series User Manual

P a g e | 69
UCM6100 Series User Manual
Version 1.0.18.13
Table 10: UCM6100 Network Settings→802.1X
802.1X Mode
Select 802.1X mode. The default setting is "Disable".
The supported 802.1X mode are:
• EAP-MD5
• EAP-TLS
• EAP-PEAPv0/MSCHAPv2
Identity
Enter 802.1X mode Identity information.
MD5 Password
Enter 802.1X mode MD5 password information.
802.1X Certificate
Select 802.1X certificate from local PC and then upload.
802.1X Client
Certificate
Select 802.1X client certificate from local PC and then upload.
Static Routes
The UCM6100 provides users static routing capability that allows the device to use manually configured routes,
rather than information only from dynamic routing or gateway configured in the UCM6100 web GUI→Network
Settings→Basic Settings to forward traffic. It can be used to define a route when no other routes are available
or necessary, or used in complementary with existing routing on the UCM6100 as a failover backup, and etc.
• Click on to create a new IPv4 static route or click on to
create a new IPv6 static route. The configuration parameters are listed in the table below.
• Once added, users can select to edit the static route.
• Select to delete the static route.
Table 11: UCM6100 Network Settings→Static Routes
Destination
Configure the destination IPv4 address or the destination IPv6 subnet for the
UCM6100 to reach using the static route.
Example:
IPv4 address - 192.168.66.4
IPv6 subnet - 2001:740:D::1/64
Netmask
Configure the subnet mask for the above destination IPv4 address. If left blank,
the default value is 255.255.255.255.
Example:
255.255.255.0
