UCM6100 Series User Manual
Version 1.0.18.13
• Ring Group
• Paging/Intercom
• Voicemail Group
• Fax
• DISA
• IVR
• Dial by Name
• External Number
• By DID
When "By DID" is used, the UCM6100 will look for the destination based on the
number dialed, which could be local extensions, conference, call queue, ring
group, paging/intercom group, IVR, voicemail groups and Fax extension as
configured in "DID destination". If the dialed number matches the DID pattern,
the call will be allowed to go through.
Configure the number of digits to be stripped from the beginning of the DID. This
option shows up only when "By DID" is selected.
Configure the number of digits to be prepended to an inbound DID pattern, with
strip taking precedence over prepend.
Select the time condition for the inbound rule.
Select the destination for the inbound call during the specified time condition.
Inbound Route: Prepend Example
UCM6100 now allows user to prepend digits to an inbound DID pattern, with strip taking precedence over
prepend. With the ability to prepend digits in inbound route DID pattern, user no longer needs to create multiple
routes for the same trunk to route calls to different extensions. The following example demonstrates the process:
1. If Trunk provides a DID pattern of 18005251163.
2. If Strip is set to 8, UCM6100 will strip the first 8 digits.
3. If Prepend is set to 2, UCM6100 will then prepend a 2 to the stripped number, now the number become
2163.
4. UCM6100 will now forward the incoming call to extension 2163.
