Grandstream Networks UCM6100 Series

To Next Page

To Previous Page

P a g e | 82

UCM6100 Series User Manual

Version 1.0.18.13

Figure 31: Fail2ban Settings

Table 18: Fail2Ban Settings

Global Settings

Enable Fail2Ban

Enable Fail2Ban. The default setting is disabled. Please make sure both "Enable

Fail2Ban" and "Asterisk Service" are turned on to use Fail2Ban for SIP

authentication on the UCM6100.

Banned Duration

Configure the duration (in seconds) for the detected host to be banned. The default

setting is 600. If set to 0, the host will be always banned.
