Grandstream Networks UCM6100 Series

To Next Page

To Previous Page

P a g e | 43

UCM6100 Series User Manual

Version 1.0.18.13

INSTALLATION

Before deploying and configuring the UCM6100 series, the device needs to be properly powered up and

connected to network. This section describes detailed information on installation, connection and warranty policy

of the UCM6100 series.

Equipment Packaging

Table 2: UCM6100 Equipment Packaging

Main Case

Yes (1)

Power Adaptor

Yes (1)

Ethernet Cable

Yes (1)

Quick Installation Guide

Yes (1)

GPL License

Yes (1)

Connect Your UCM6100

Connect The UCM6102

Figure 1: UCM6102 Front View
