Grandstream Networks UCM6100 Series User Manual

P a g e | 79
UCM6100 Series User Manual
Version 1.0.18.13
Figure 29: Create New Firewall Rule
Table 16: Firewall Rule Settings
Rule Name
Specify the Firewall rule name to identify the firewall rule.
Action
Select the action for the Firewall to perform.
• ACCEPT
• REJECT
• DROP
Type
Select the traffic type.
• IN
If selected, users will need specify the network interface "LAN" or "WAN"
(for UCM6100) for the incoming traffic.
• OUT
Service
Select the service type.
• FTP
• SSH
• Telnet
• TFTP
• HTTP
• LDAP
• Custom
If "Custom" is selected, users will need specify Source (IP and port),
Destination (IP and port) and Protocol (TCP, UDP or Both) for the service.
Please note if the source or the destination field is left blank, it will be used
as "Anywhere".
