UCM6100 Series User Manual
Version 1.0.18.13
• Local USB Media
If selected, the USB storage device needs to be plugged into the
UCM6100 and the firmware file must be put under a folder named
“ZC_firmware” in the USB storage root directory.
• Local SD Card Media
If selected, an SD card needs to be plugged into the UCM6100 and the
firmware file must be put under a folder named “ZC_firmware” in the
USB storage root directory.
When URL is selected as firmware source, configure upgrade via TFTP,
HTTP or HTTPS.
When URL is selected as firmware source, configure the firmware
upgrading server path.
When URL is selected as firmware source, configure the firmware file
prefix. If configured, only the firmware with the matching encrypted prefix
will be downloaded and flashed into the phone, if URL is selected as
firmware source.
When URL is selected as firmware source, configure the firmware file
postfix. If configured, only the configuration file with the matching encrypted
postfix will be downloaded and flashed into the phone.
If DHCP option 43 or 66 is enabled on the LAN side, the TFTP server can
be redirected.
If enabled, the end point device will automatically upgrade if a new firmware
is detected. Users can select automatic upgrading by day, by week or by
minute.
• By week
Once selected, specify the day of the week to check HTTP/TFTP
server for firmware upgrades or configuration files changes.
• By day
Once selected, specify the hour of the day to check the HTTP/TFTP
server for firmware upgrades or configuration files changes.
• By minute
Once selected, specify the interval X that the SIP end device will
request for new firmware every X minutes.
Specify how firmware upgrading and provisioning request to be sent.
Configure the administrator password for admin level login.
Configure the end-user password for the end user level login.
Select HTTP or HTTPS as the web access protocol.
