Grandstream Networks UCM6100 Series User Manual

P a g e | 184
UCM6100 Series User Manual
Version 1.0.18.13
Username
Enter the username to register to the trunk from the provider when "Register SIP
Trunk" type is selected.
Password
Enter the password to register to the trunk when "Register SIP Trunk" is selected.
Auth ID
Enter the Authentication ID for "Register SIP Trunk" type.
Auth Trunk
If enabled, the UCM will send 401 response to the incoming call to authenticate
the trunk.
Auto Record
Enable automatic recording for the calls using this trunk (for SIP trunk only). The
default setting is disabled. The recording files can be accessed under Web
GUI→CDR→Recording Files.
Direct Callback
Allows external numbers the option to get directed to the extension that last called
them.
For Example: User 2002 has dialed external number 061234575 but they were not
reachable, once they have received missed call notification on their phone, they
would mostly call back the number, if the option “Direct Callback” is enabled then
they will be directly bridged to user 2002 regardless of the configured inbound
destination.
Advanced Settings
Codec Preference
Select audio and video codec for the VoIP trunk. The available codecs are: PCMU,
PCMA, GSM, AAL2-G.726-32, G.726, G.722, G.729, G.723, iLBC, ADPCM,
H.264, H.265, H.263, H.263p and VP8.
Send PPI Header
If enabled, the SIP INVITE message sent to the trunk will contain PPI (P-Preferred-
Identity) header. The default setting is “No”.
Note: “Send PPI Header” and “Send PAI Header” cannot be enabled at the same
time. Only one of the two headers can be contained in SIP INVITE message.
PPI Mode
• Default – Include the trunk’s preferred CID (configured in Basic Settings)
in the PPI Header.
• Original CID – Include the original CID in the PPI Header.
• DOD Number – Include the trunk’s DOD number in the PPI Header. If no
DOD number has been set, the trunk’s preferred CID will be used.
Send PAI Header
If enabled, the SIP INVITE message sent to the trunk will contain PAI (P-Asserted-
Identity) header including configured PAI Header. The default setting is “No”.
Note: “Send PPI Header” and “Send PAI Header” cannot be enabled at the same
time. Only one of the two headers can be contained in the SIP INVITE message.
PAI Header
If “Send PAI Header” is enabled and “PAI Header” is configured as “123456” for
instance, the PAI header in the SIP message sent from the UCM will contain
“123456”. If “Send PAI Header” is enabled and “PAI Header” is configured as
“empty”, the PAI header in the SIP message sent from the UCM will contain the
original CID.
