UCM6100 Series User Manual
Version 1.0.18.13
Minimum Transfer Rate
Configure the minimum transfer rate during the Fax rate negotiation. The
possible values are 2400, 4800, 7200, 9600, 12000 and 14000. The default
setting is 2400.
Max Concurrent
Sending Fax
Configure the concurrent fax that can be sent by UCM6100. Two modes “Only”
and “More” are supported.
• Only
Under this mode, the UCM6100 allows only single user to send fax at a time.
• More
Under this mode, the UCM6100 supports multiple concurrent fax sending by
the users.
By default, this option is set to “only”.
Fax Queue Length
Configure the maximum length of Fax Queue from 6 to 10.
The default setting is 6.
Fax Header Information
Adds fax header into the fax file.
Default Email Address
Configure the Email address to send the received Fax to if user's Email address
cannot be found.
Note:
The extension's Email address or the Fax's default Email address needs to be
configured in order to receive Fax from Email. If neither of them is configured,
Fax will not be received from Email.
Template Variables
Fill in the "Subject:" and "Message:" content, to be used in the Email when
sending the Fax to the users.
The template variables are:
• ${CALLERIDNUM} : Caller ID Number
• ${CALLERIDNAME} : Caller ID Name
• ${RECEIVEEXTEN} : The extension to receive the Fax
• ${FAXPAGES} : Number of pages in the Fax
• ${VM_DATE} : The date and time when the Fax is received
Enable Fax Resend
Enables the fax resend option which allow the UCM to keep attempting to send
faxes up to a specified amount of times. Additionally, if a fax still fails to send, a
Resend button will appear in the File Send Progress list in Value-Added
Features->Fax Sending to allow manual resending.
Max Resend Attempts
Configures the maximum attempts number to resend the FAX.
