UCM6100 Series User Manual
Version 1.0.18.13
Select DTMF mode to send DTMF. The default setting is RFC2833. If "Info" is
selected, SIP INFO message will be used. If "Inband" is selected, 64-kbit codec
PCMU and PCMA are required. When "Auto" is selected, "RFC2833" will be used
if offered, otherwise "Inband" will be used. The default setting is "RFC2833".
During an active call, if there is no RTP activity within the timeout (in seconds),
the call will be terminated. The default setting is no timeout.
Note:
This setting doesn't apply to calls on hold.
When the call is on hold, if there is no RTP activity within the timeout (in seconds),
the call will be terminated. This value of RTP Hold Timeout should be larger than
RTP Timeout. The default setting is no timeout.
This feature can be used to avoid abnormal call drop when the remote provider
requires RTP traffic during proceeding.
For example, when the call goes into voicemail and there is no RTP traffic sent
out from UCM, configuring this option can avoid voicemail drop.
When configured, RTP keep-alive packet will be sent to remote party at the
configured interval. If set to 0, RTP keep-alive is disabled.
Configure the 100rel setting on UCM6100. The default setting is “Yes”.
Configure whether the Remote-Party-ID should be trusted. The default setting is
"No".
Configure whether the Remote-Party-ID should be sent or not. The default
setting is "No".
Configure whether the UCM6100 should generate inband ringing or not. The
default setting is "Never".
• Yes: The UCM6100 will send 180 Ringing followed by 183 Session Progress
and in-band audio.
• No: The UCM6100 will send 180 Ringing if 183 Session Progress has not
been sent yet. If audio path is established already with 183 then send in-
band ringing.
• Never: Whenever ringing occurs, the UCM6100 will send 180 Ringing as
long as 200OK has not been set yet. Inband ringing will not be generated
even the end point device is not working properly.
Configure the user agent string for the UCM6100.
If enabled, compact SIP headers will be sent. The default setting is "No".
