Preferred DNS Server
Enter the preferred DNS server address. If Preferred DNS is used, UCM will try to
use it as Primary DNS server.
IP Method
Select DHCP, Static IP, or PPPoE. The default setting is DHCP.
IP Address
Enter the IP address for static IP settings.
Subnet Mask
Enter the subnet mask address for static IP settings.
Gateway IP
Enter the gateway IP address for static IP settings.
DNS Server 1
Enter the DNS server 1 address for static IP settings.
DNS Server 2
Enter the DNS server 2 address for static IP settings.
User Name
Enter the user name to connect via PPPoE.
Password
Enter the password to connect via PPPoE.
Layer 2 QoS
802.1Q/VLAN Tag
Assign the VLAN tag of the layer 2 QoS packets for LAN port.
The default value is 0.
Layer 2 QoS 802.1p
Priority Value
Assign the priority value of the layer 2 QoS packets for LAN port.
The default value is 0.
IPv6 Address
IP Method
Select Auto or Static. The default setting is Auto
IP Address
Enter the IP address for static IP settings.
IP Prefixlen
Enter the Prefix length for static settings. Default is 64
DNS Server 1
Enter the DNS server 1 address for static settings.
DNS Server 2
Enter the DNS server 2 address for static settings.
• Method: Route
When the UCM6102 has method set to Route in network settings, WAN port interface is used for uplink
connection and LAN port interface is used as a router. Please see a sample diagram below.
