Table 49: PSTN Detection for Analog Trunk

Detect Model

Select "Auto Detect" or "Semi-auto Detect" for PSTN detection.

 Auto Detect

Please make sure two or more channels are connected to the

UCM6100 and in idle status before starting the detection. During the

detection, one channel will be used as caller (Source Channel) and

another channel will be used as callee (Destination Channel). The

UCM6100 will control the call to be established and hang up between

caller and callee to finish the detection.

 Semi-auto Detect

Semi-auto detection requires answering or hanging up the call

manually. Please make sure one channel is connected to the

UCM6100 and in idle status before starting the detection. During the

detection, source channel will be used as caller and send the call to

the configured Destination Number. Users will then need follow the

prompts in web GUI to help finish the detection.

The default setting is "Auto Detect".

Source Channel

Select the channel to be detected.

Destination Channel

Select the channel to help detect when "Auto Detect" is used.

Destination Number

Configure the number to be called to help the detection.

--------------------------------------------------------------------------------------------------------------------------------------------

Note:

 The PSTN detection process will keep the call up for about 1 minute.

 If "Semi-auto Detect' is used, please pick up the call only after informed from the web GUI prompt.

 Once the detection is successful, the detected parameters "Busy Tone", "Polarity Reversal" and

"Current Disconnect by PSTN" will be filled into the corresponding fields in the analog trunk

configuration.

--------------------------------------------------------------------------------------------------------------------------------------------

VOIP TRUNKS

VoIP trunks can be configured in UCM6100 under Web GUI->PBX->Basic/Call Routes->VoIP Trunks.

Once created, the VoIP trunks will be listed with Provider Name, Type, Hostname/IP, Username and

Options to edit/detect the trunk.
