UCM6100 Series IP PBX User Manual

Page 291 of 305

Figure 179: Upgrading Firmware Files

 Wait until the upgrading process is successful and a window will be popped up in the Web GUI.

Figure 180: Reboot UCM6100

 Click on "OK" to reboot the UCM6100 and check the firmware version after it boots up.

--------------------------------------------------------------------------------------------------------------------------------------------

Note:

Please do not interrupt or power cycle the UCM6100 during upgrading process.

--------------------------------------------------------------------------------------------------------------------------------------------
