Firmware Version 1.0.9.26
UCM6100 Series IP PBX User Manual
To access the Web GUI:
1. Connect the computer to the same network as the UCM6100.
2. Ensure the device is properly powered up and shows its IP address on the LCD.
3. Open a Web browser on the computer and enter the web GUI URL in the following format:
http(s)://IP-Address:Port
where the IP-Address is the IP address displayed on the UCM6100 LCD.
By default, the protocol is HTTPS and the Port number is 8089.
For example, if the LCD shows 192.168.40.167, please enter the following in your web browser:
https://192.168.40.167:8089
4. Enter the administrator’s login and password to access the Web Configuration Menu. The default
administrator's username and password is "admin" and "admin". It is highly recommended to change
the default password after login for the first time.
--------------------------------------------------------------------------------------------------------------------------------------------
Note:
By default, the UCM6100 has "Redirect From Port 80" enabled. Therefore, if users type in the UCM6100 IP
address in the web browser, the web page will be automatically redirected to the page using HTTPS and
port 8089. For example, if the LCD shows 192.168.40.167, please enter 192.168.40.167 in your web
browser and the web page will be redirected to:
https://192.168.40.167:8089
The option "Redirect From Port 80" can be configured under the UCM6100 web GUI->Settings->HTTP
Server.
--------------------------------------------------------------------------------------------------------------------------------------------
WEB GUI CONFIGURATIONS
There are four main sections in the Web GUI for users to view the PBX status, configure and manage the
PBX.
ï‚· Status: Displays PBX status, System Status, System Events and CDR.
ï‚· PBX: To configure extensions, trunks, call routes, zero config for auto provisioning, call features,
internal options, IAX settings and SIP settings.
