Grandstream Networks UCM6102 User Manual

Firmware Version 1.0.9.26
UCM6100 Series IP PBX User Manual
Page 28 of 305
TECHNICAL SPECIFICATIONS
Table 1: Technical Specifications
Interfaces
Analog Telephone FXS Ports
2 ports (both with lifeline capability in case of power outage)
PSTN Line FXO Ports
 UCM6102: 2 ports
 UCM6104: 4 ports
 UCM6108: 8 ports
 UCM6116: 16 ports
Network Interfaces
 UCM6102/6104: Dual 10M/100M/1000M RJ45 Ethernet ports with
integrated PoE Plug (IEEE 802.3at-2009)
 UCM6108/6116: Single 10M/100M/1000M RJ45 Ethernet port with
integrated PoE Plug (IEEE 802.3at-2009)
NAT Router
Yes, UCM6102 only
Peripheral Ports
USB, SD/SDHC (VFAT)
LED Indicators
Power/Ready, Network, PSTN Line, USB, SD
LCD Display
128x32 graphic LCD with DOWN and OK button
Reset Switch
Yes
Voice/Video Capabilities
Voice-over-Packet
Capabilities
LEC with NLP Packetized Voice Protocol Unit, 128ms-tail-length carrier
grade Line Echo Cancellation, Dynamic Jitter Buffer, Modem detection
and auto-switch to G.711
Voice and Fax Codecs
G.711 A-law/U-law, G.722, G.723.1 5.3K/6.3K, G.726, G.729A/B, iLBC
(30ms only), GSM; T.38
Video Codecs
H.264, H.263, H.263+
QoS
Layer 3 QoS
Signaling and Control
DTMF Methods
In Audio, RFC2833, and SIP INFO
Provisioning Protocol and
Plug-and-Play
TFTP/HTTP/HTTPS, auto-discovery and auto-provisioning of
Grandstream IP endpoints via ZeroConfig (DHCP Option 66/multicast SIP
SUBSCRIBE/mDNS)
Network Protocols
TCP/UDP/IP, RTP/RTCP, ICMP, ARP, DNS, DDNS, DHCP, NTP, TFTP,
SSH, HTTP/HTTPS, PPPoE, SIP (RFC3261), STUN, SRTP, TLS
Disconnect Methods
Call Progress Tone, Polarity Reversal, Hook Flash Timing, Loop Current
Disconnect, Busy Tone
