Grandstream Networks UCM6102 User Manual

Firmware Version 1.0.9.26
UCM6100 Series IP PBX User Manual
Page 286 of 305
CDR Statistics is an additional feature on the UCM6100 which provides users a visual overview of the call
report across the time frame. Users can filter with different criteria to generate the statistics chart.
Figure 175: CDR Statistics
Table 101: CDR Statistics Filter Criteria
Trunk Type
Select one of the following trunk type.
 All
 SIP Calls
 PSTN Calls
Call Type
Select one or more in the following checkboxes.
 Inbound calls
 Outbound calls
 Internal calls
 External calls
 All calls
Time Range
 By month (of the selected year).
 By week (of the selected year).
 By day (of the specified month for the year).
 By hour (of the specified date).
 By range. For example, 2013-01 To 2013-03.
RECORDING FILES
This page lists all the recording files recorded by "Auto Record" per extension/ring group/call queue/trunk,
or via feature code "Audio Mix Record". If external storage device is plugged in, for example, SD card or
USB drive, the files are stored on the external storage. Otherwise, internal storage will be used on the
UCM6100.
